Power Tank EV Charger

Product Overview & Key Features Key Highlights: 3.5 kW fast charging (16A fixed output) Works with standard 16A single-phase sockets Plug & play – no installation required Smart display with real-time data Automatic start & stop charging Scheduled charging (0–10 hours delay) Heavy-duty build for daily use Built for Safety: Over-voltage & under-voltage protection Over-current & overload protection Short-circuit protection Temperature protection Leakage & grounding protection Requires proper earthing (≤ 5 ohms). Charger will not operate without safe grounding. Advanced Digital Display & Smart Features Real-time Display: Voltage Current Temperature Energy consumption Smart Features: “CC” indicator confirms correct connection Auto stops when battery is full Resume charging automatically when safe conditions return Durable & Weather-Ready Build IP55 rated – suitable for indoor & outdoor use Works in -20°C to 50°C conditions Strong thermoplastic body Heavy-duty cable built for long-term use Compatibility & Usage Requirements Compatibility: Type 2 EV compatible (IEC 61851 standard) Works with most electric cars in India Designed for stable performance on Indian power supply Usage Requirements: Requires 16A socket (do not use 6A or adapters) Proper earthing is mandatory Avoid tightly coiling cable during use Suitable for home, travel, and commercial use Technical Specifications Rated Power: 3.5 kW Rated Current: 16A Rated Voltage: AC 230V ±10% Cable Length: 5 meters Protection Rating: IP55 Operating Temperature: -20°C to 50°C Weight: ~2.2 kg Standard: IEC 61851 What’s in the Box EV Charger Storage Bag User Manual Certificate Warranty & Support 3 Year Wundercurrent Warranty Free doorstep pickup & drop service Covers manufacturing defects under normal use Support: Email: [email protected] Phone: 91 9313197730 FAQs What type of socket is required for this charger? This charger works only with a standard 16A single-phase socket. Do not use a 6A socket or adapters. What is the charging power output? The charger delivers up to 3.5 kW (16A fixed output) for consistent charging. Does this charger require earthing? Yes. Proper earthing (≤ 5 ohms) is mandatory for safe operation. Without it, the charger will not start. What happens if voltage fluctuates during charging? The charger automatically detects unsafe voltage levels and activates protection. Charging will resume once the voltage returns to normal. Can I use this charger outdoors? Yes, it is suitable for outdoor use, but should not be exposed to heavy rain or submerged in water. What is the operating temperature range? The charger works safely between -20°C to 50°C. Does the charger stop automatically after full charge? Yes. Charging stops automatically once the vehicle battery is full. How do I start charging? Plug into a 16A socket, connect to your vehicle, and charging starts automatically. Does it support scheduled/delay charging? Yes. You can set delay charging from 0 to 10 hours using the button on the device. What information is shown on the display? It shows real-time current, voltage, temperature, and energy consumed. What does “CC” on the display mean? It indicates the charger is properly connected to the vehicle. Can I touch the connector while charging? No. Avoid touching metal parts during charging as high current flows through them. What safety protections are included? Protections include: Over-voltage & under-voltage Over-current & overload Short-circuit protection Temperature protection Leakage & grounding protection What should I do if the charger shows an error? Check power supply, earthing, and connections. If the issue persists, contact customer support. Can I coil the cable while charging? No. Avoid tightly winding the cable during use to prevent overheating and damage. Is installation required? No fixed installation is required, but ensure your electrical system is suitable. A qualified electrician is recommended for setup checks. What is the cable length? The charger comes with a 5-meter cable for flexible use. What comes in the box? Charger Storage bag User manual Certificate
